Brand: Vargus / Part #: 049-00005
Item #: 88215793
Brand: Vargus
Model #: 049-00005
Product Specifications
| Material | Carbide |
| Thread Size (mm) | M5x0.8 |
| Thread Depth (Decimal Inch) | 0.425 |
| Thread Type | Internal |
| Shank Diameter (mm) | 4.0000 |
| Shank Diameter (Decimal Inch) | 0.1575 |
| Cutting Diameter (mm) | 3.90 |
| Cutting Diameter (Decimal Inch) | 0.1535 |
| Length of Cut (mm) | 10.8000 |
| Minimum Nominal Diameter (Decimal Inch) | 0.1969 |
| Minimum Nominal Diameter (mm) | M5 |
| Shank Length (Decimal Inch) | 1.2700 |
| Shank Length (mm) | 20.000 |
| Overall Length (mm) | 34.0000 |
| Overall Length (Decimal Inch) | 1.3386 |
| Number Of Flutes | 4 |
| Coating/Finish | TiCN |
| Coolant Through | Yes |
| Length Of Cut (Decimal Inch - 4 Decimals) | 0.4252 |
| Thread Length (mm) | 10.80 |
| Thread Length (Decimal Inch) | 2.3510 |
