3/32″ Cutting Dia. × 1/8″ Shank Size × 0.139″ LOC × 2-1/2″ OAL, 3 Flute, Carbide, AlTiN, 1/64″ Corner Radius End Mill
Item #: GE90765893C3
Brand: Harvey Tool
Model #: 765893-C3
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 3/32″ |
| Corner Radius (RE) | 1/64″ |
| Connection Diameter Machine Side (DCONMS) | 1/8″ |
| Neck Diameter (DN) | 0.0915″ |
| Depth of Cut Maximum (APMX) | 0.139″ |
| Length Group | 6D |
| Overall Length (OAL) | 2-1/2″ |
| Flute Type | Spiral |
| Cutting Edge Material | Carbide |
| Body Material | Carbide |
| Coating | AlTiN |
| Decimal Equivalent | 0.093″ |
| Flute Count (NOF) | 3 |
| Measurement Type | Inch |
| Flute Helix Angle (FHA) | 30 Degrees |
| Shank Size (SS) | 1/8″ |
| Shank Type | Round |
| Corner Radius (RE) / Chamfer Width (CHW) | 1/64″ |
| End Shape | Corner Radius |
| Cutting Direction (HAND) | Right Hand |
| Usable Length (LU) | 0.585″ |
| Single / Double End | Single End |
