Brand: Ingersoll Cutting Tools / Part #: 6133585
Item #: 98813041
Brand: Ingersoll Cutting Tools
Model #: 6133585
Product Specifications
| Minimum Drill Diameter (mm) | 35.00 |
| Maximum Drill Diameter (mm) | 35.90 |
| Drill Depth by Diameter Ratio | 5xD |
| Maximum Drill Depth (mm) | 180.57 |
| Shank Type | Flatted |
| Insert Style | LPF; LPA |
| Insert Seat Size | 35 |
| Shank Diameter (mm) | 40.0000 |
| Tool Material | Steel |
| Compatible Insert Style | LPF; LPA |
| Compatible Insert Size Code | 36..; 35..; 37.. |
| Overall Length (mm) | 275.8800 |
| Series | LD |
| Toolholder Style | LD |
| Flute Length (mm) | 205.88 |
| Body Length | 205.880 |
| Shank Length (mm) | 70.000 |
| Tool Application | Drilling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Cutting Direction | Right Hand |
| Coolant Through | Yes |
