Brand: Widia / Part #: 6372043
Item #: 04353926
Brand: Widia
Model #: 6372043
Product Specifications
| Insert Style | TCF |
| Insert Size Code | 070306 |
| Insert Material | Carbide |
| Manufacturer Grade | WN10PH |
| Inscribed Circle (Decimal Inch) | 0.2627 |
| Cutting Direction | Neutral |
| Corner Radius (Decimal Inch) | 0.0236 |
| Chipbreaker | V36 |
| Series | TCF |
| Coating Process | PVD |
| Shape | Irregular |
| Hole Diameter (Decimal Inch) | 0.1024 |
| Number Of Cutting Edges | 4 |
| Relief Angle | 11.000 |
| Rake | Positive |
| Primary Workpiece Material | Non-Ferrous Metal |
| Primary Workpiece Material Code | N |
| Ansi Code | TCF070306CPV36 |
| Iso Code | TCF070306CPV36 |
| Drill Style | TCF |
| Insert Size | 07 |
| Coating Classification | PVD |
| Width (Decimal Inch - 4 Decimals) | 0.2795 |
| Length (Decimal Inch - 4 Decimals) | 0.2795 |
| Included Angle Degree | 90 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1102 |
| Coating/Finish | TiB2 |
