1/4″ Dia. × 1/4″ Shank × 1.668″ DOC × 4 OAL, Carbide nACo, 4 Flute, Ballnose End Mill
Item #: CR10H7356
Brand: Melin Tool Co
Model #: H7356
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1/4″ |
| Flute Count (NOF) | 4 |
| Connection Diameter Machine Side (DCONMS) | 1/4″ |
| Usable Length (LU) | 0.168″ |
| Depth of Cut Maximum (APMX) | 1.668″ |
| End Shape | Ball 220° |
| Overall Length (OAL) | 4 |
| Decimal Equivalent | 0.25″ |
| Cutting Edge Material | Carbide |
| Series/List # | VBMG4 |
| Coating | nACo |
