Brand: Widia / Part #: 2822637

Brand: Widia / Part #: 2822637


Item #: 02770873
Brand: Widia
Model #: 2822637

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.6800
Maximum Bore Depth (Decimal Inch) 1.8750
Toolholder Style SSBI
Tool Material Steel
Shank Diameter (Decimal Inch) 0.6250
Hand of Holder Right Hand
Shank Diameter (Inch) 5/8
Overall Length (Decimal Inch) 7.0000
Overall Length (Inch) 7
Compatible Insert Size Code CP..3252
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle 0.000
Lead Angle -5.000
Series SSBIC
Insert Inscribed Circle (Inch) 3/8
Compatible Insert Thickness (Decimal Inch) 0.1563
Compatible Insert Thickness (mm) 3.97
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.6655
Center to Cutting Edge (Decimal Inch) 0.3530
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Neck Diameter (Decimal Inch) 0.6350
Insert Thickness (Decimal Inch) 0.1563
Insert Thickness (Inch) 5/32
Coolant Hole Diameter (Decimal Inch) 0.1560
Number of Inserts Included in Order 0
Manufacturers Catalog Number SSBIC62575R
Radial Rake 0
Coolant Through Yes
$ 116.36
