F90SD D125-09-40-12
Item #: EH313319628
Brand: Iscar
Model #: 3319628
| Product Specifications | |
|---|---|
| Cutting Diameter (DC/DCX) | 125 mm |
| Master Insert Identification (MIID) | SDMT 1205PDR-HQ-M |
| Cutting Diameter (DC) | 125 mm |
| Coolant Supply Property (CSP) | Through Hole |
| Cutting Item Count (CICT) | 9 |
| Body Material | Steel |
| Depth of Cut Maximum (APMX) | 11.8 mm |
| Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 40 mm |
| Application | | Facing | Shouldering | Slotting | |
| Overall Length (OAL) | 50.35 mm |
| Measurement Type | Metric |
| Hub Diameter (DHUB) | 92 mm |
| Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Arbor Style | B |
