SDN D5.0-0.50-10-XN09
Item #: EH313393670
Brand: Iscar
Model #: 3393670
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 5″ |
| Overall Length (OAL) | 5/8″ |
| Cutting Item Count (CICT) | 14 |
| Master Insert Identification (MIID) | XNMU 090446 |
| Peripheral Effective Cutting Edge Count (ZEFP) | 7 |
| Application | | Bottom Shouldering | Shouldering | Side Slotting | Slotting | |
| Cutting Depth Maximum (CDX) | 1.4″ |
| Tool Type | Double-sided slotting cutters |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ |
| Measurement Type | Inch |
| Hub Diameter (DHUB) | 2″ |
| Body Material | Steel |
| Cutting Width (CW) | 1/2″ |
