Brand: Widia / Part #: 2951399

Brand: Widia / Part #: 2951399


Item #: 02769131
Brand: Widia
Model #: 2951399

Product Specifications

Minimum Bore Diameter (Decimal Inch) 1.2000
Maximum Bore Depth (Decimal Inch) 3.0000
Toolholder Style SCLCR
Tool Material Steel
Shank Diameter (Decimal Inch) 1.0000
Hand of Holder Right Hand
Shank Diameter (Inch) 1
Overall Length (Decimal Inch) 12.0000
Overall Length (Inch) 12
Compatible Insert Size Code CC..3252
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle -4.000
Lead Angle -5.000
Series A-SCLC
Insert Inscribed Circle (Inch) 3/8
Compatible Insert Thickness (Decimal Inch) 0.1563
Compatible Insert Thickness (mm) 3.97
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 1.1400
Center to Cutting Edge (Decimal Inch) 0.6400
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.1563
Insert Thickness (Inch) 5/32
Number of Inserts Included in Order 0
Manufacturers Catalog Number A16TSCLCR3
Radial Rake 0
Coolant Through Yes
