1/2-13 3FL H-5 PENTA BLUE CNC DESIGN SPPT PLUG TAPS 402VPR (86948) TD1
Item #: EP4086949
Brand: Reiff & Nestor
Model #: 86949
| Product Specifications | |
|---|---|
| Thread Standard | NC |
| Thread Cutting Part Length (THL) | 15/16″ |
| Thread Size | 1/2″ - 13 |
| Drive Size (DRVS) | 0.275″ |
| Thread Diameter Size (TDZ) | 1/2″ |
| Flute Length | 15/16″ |
| Threads per Inch (TPI) | 13 |
| Flute Type | Straight |
| Thread Tolerance Class (TCTR) | H5 |
| End Shape | Spiral Point |
| Usable Length (LU) | 15/16″ |
| Style | Plug |
| Overall Length (OAL) | 3-3/8″ |
| Shank Type | Round |
| Coating | Blue Diamond |
| Cutting Direction (HAND) | Right Hand |
| Flute Count (NOF) | 3 |
| Square Size | 0.275″ × 7/16″ |
| Cutting Edge Material | HSS |
| Measurement Type | Inch |
| Tool Type | Tap |
| Series/List # | 402VPR |
| Connection Diameter Machine Side (DCONMS) | 0.275″ |
| Grade | HSS |
