MTSH 1212 D35 18 UN MT9
Item #: FF5840300221
Brand: Carmex
Model #: 40300221
| Product Specifications | |
|---|---|
| Thread Size | 2xD|5/8 |
| Application | MILL THREAD SOLID CARBIDE HARDCUT |
| Threads per Inch (TPI) | 18 |
| Applicable Material | Cast Iron |
| Thread Standard | UN |
| Cutting Edge Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 12 mm |
| Cutting Position | Internal |
| Cutting Diameter (DC) | 12 mm |
| Series/List # | MTSH |
| Functional Length (LF) | 35 mm |
| Measurement Type | Metric |
| Overall Length (OAL) | 84 mm |
| Grade | MT9 |
| Coolant Supply Property (CSP) | No |
| Cutting Direction (HAND) | Left Hand|Right Hand |
| Coating | Advanced PVD 3x Ultra-Fine Sub-Micron Coated |
