MTI 0500 D12 6 ACME MT8
Item #: FF5840300331
Brand: Carmex
Model #: 40300331
| Product Specifications | |
|---|---|
| Thread Size | 3/4 - 6|7/8 - 6 |
| Coating | TiAlN |
| Threads per Inch (TPI) | 6 |
| Application | MINI MILL THREAD |
| Thread Standard | ACME |
| Applicable Material | General Purpose |
| Connection Diameter Machine Side (DCONMS) | 5 mm |
| Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 12 mm |
| Cutting Position | Internal |
| Functional Length (LF) | 30.5 mm |
| Series/List # | MTI |
| Overall Length (OAL) | 3.5″ |
| Measurement Type | Metric |
| Flute Count (NOF) | 4 |
| Grade | MT8 |
| Coolant Supply Property (CSP) | No |
| Cutting Direction (HAND) | Left Hand|Right Hand |
