MTZ 12109 D28 11 W MT7
Item #: FF5840600010
Brand: Carmex
Model #: 40600010
| Product Specifications | |
|---|---|
| Thread Size | 5/8 |
| Coating | TiAlN |
| Threads per Inch (TPI) | 11 |
| Application | MILL THREAD SOLID CARBIDE |
| Thread Standard | WHITWORTH (BSW) |
| Applicable Material | General Purpose |
| Connection Diameter Machine Side (DCONMS) | 12 mm |
| Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 10.9 mm |
| Cutting Position | Internal |
| Functional Length (LF) | 28.9 mm |
| Series/List # | MTZ |
| Overall Length (OAL) | 3.3″ |
| Measurement Type | Metric |
| Flute Count (NOF) | 4 |
| Grade | MT7 |
| Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Direction (HAND) | Left Hand|Right Hand |
