MIL 10 L35 2 TR BXC
Item #: FF5870400123
Brand: Carmex
Model #: 70400123
| Product Specifications | |
|---|---|
| Thread Pitch (TP) | 02.00mm |
| Overall Length (OAL) | 73.66 mm |
| Cutting Direction (HAND) | Left Hand |
| Minimum Bore Diameter (DMIN) | 10.92 mm |
| Cutting Edge Material | Carbide |
| Grade | BXC |
| Connection Diameter Machine Side (DCONMS) | 10 mm |
| Coolant Supply Property (CSP) | Coolant Thru |
| Thread Angle | 30 Degrees |
| Size | H10 |
| Applicable Material | Stainless Steel |
| Cutting Length | 35.05 mm |
| Coating | TiN |
| Thread Size | 14 × 2 | 16 × 2 | 18 × 2 | 20 × 2 |
| Measurement Type | Metric |
| Internal/External | Internal |
