MIR 10 L35 8 ACME BXC
Item #: FF5870400132
Brand: Carmex
Model #: 70400132
| Product Specifications | |
|---|---|
| Cutting Direction (HAND) | Right Hand |
| Minimum Bore Diameter (DMIN) | 12.45 mm |
| Cutting Edge Material | Carbide |
| Grade | BXC |
| Connection Diameter Machine Side (DCONMS) | 10 mm |
| Threads per Inch (TPI) | 8 |
| Thread Angle | 29 Degrees |
| Coolant Supply Property (CSP) | Coolant Thru |
| Applicable Material | Stainless Steel |
| Size | H10 |
| Coating | TiN |
| Cutting Length | 35.05 mm |
| Measurement Type | Metric |
| Thread Size | 5/8 × 8 |
| Overall Length (OAL) | 76.2 mm |
| Internal/External | Internal |
