Cle-Line - Jobber Length Drill Bits Drill Bit Size (Inch): 5/32 Drill Bit Size (Decimal Inch): 0.1600
Item #: 14283931
Brand: Cle-Line
Model #: C97307
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Titanium nitride tip (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools. Similar, but more economical than TiN.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Jobber Length Drill Bits; Drill Bit Size (Inch): 5/32 ; Drill Bit Size (Decimal Inch): 0.1600 ; Drill Point Angle: 118 ; Drill Bit Material: High Speed Steel ; Drill Bit Finish/Coating: TiN (Tip) ; Flute Type: Spiral
| Drill Bit Size (Inch) | 5/32 |
| Drill Bit Size (Decimal Inch) | 0.1600 |
| Drill Point Angle | 118 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | TiN (Tip) |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (Decimal Inch) | 2.0000 |
| Overall Length (Decimal Inch) | 3.13000 |
| Flute Length x Diameter Ratio | 3xD |
| Point Type | Split Point |
| Shank Diameter (Decimal Inch) | 0.1600 |
| Maximum Drilling Depth (Decimal Inch) | 0.3900 |
| Spiral Type | Regular Spiral |
| Shank Length (Inch) | 1-1/8 |
| Specification Designation | ANSI |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0007 |
| Number of Flutes | 2 |
| PSC Code | 5133 |
| Drill Bit Grade | General Purpose |
| Series/List | 1500-TT |
