Allied Machine and Engineering - 17mm to 18mm Diam 5xD 89.9mm Max Depth Straight Flute Spade Drill
Item #: 95658803
Brand: Allied Machine and Engineering
Model #: ST05170-20FM
Features and Benefits
Straight flutes are used for horizontal machining center applications.
| Product Specifications | |
|---|---|
| Series | 17 |
| Minimum Drill Diameter (mm) | 17.00 |
| Maximum Drill Diameter (mm) | 18.00 |
| Shank Type | Straight Shank with Flange |
| Shank Diameter (mm) | 20.00 |
| Overall Length (mm) | 170.00 |
| Drill Depth by Diameter Ratio | 5xD |
| Maximum Drill Depth (mm) | 89.90 |
| Flute Type | Straight Flute |
| Body Length (mm) | 120.00 |
| Shank Length (mm) | 50.00 |
| Series Code/Seat Size | 17 |
| Through Coolant | Yes |
| Toolholder Material | Steel |
| Coolant Hole Thread Type | NPT |
| Shank End Coolant Hole Thread Size (Inch) | 1/8 |
