16IR A60 GP50A
Item #: FG322450465
Brand: Tool-Flo
Model #: 2450465
| Product Specifications | |
|---|---|
| Thread Standard | THFT |
| Chip Breaker Type | Z |
| Inscribed Circle Diameter (IC) | 3/8″ |
| Shape | 60° Triangle |
| Insert Length (INSL) | 0.63″ |
| Threads per Inch Minimum (TPIN) | 16 Threads/" |
| Corner Radius (RE) | 0.0016″ |
| Threads per Inch Maximum (TPIX) | 48 Threads/" |
| Grade | GP50A TiCN | TiN |
| Thread Pitch Minimum (TPN) | 0.5 mm |
| Coating | TiCN+TiN |
| Thread Pitch Maximum (TPX) | 1.5 mm |
| Cutting Edge Material | Carbide |
| Tool Type | Threading Regular Inserts |
| Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Measurement Type | Inch |
| Applicable Material | | Steel | Stainless Steel | |
| Body Material | Carbide |
| Cutting Direction (HAND) | Right Hand |
| Thread Form Type (THFT) | VP60 |
