16ER 0.70ISO GP50A
Item #: FG322478067
Brand: Tool-Flo
Model #: 2478067
| Product Specifications | |
|---|---|
| Inscribed Circle Diameter (IC) | 9.52 mm |
| Cutting Direction (HAND) | Right Hand |
| Insert Length (INSL) | 16 mm |
| Chip Breaker Type | Z |
| Thread Pitch (TP) | 0.7 mm |
| Shape | Triangle |
| Corner Radius (RE) | 0.11 mm |
| Cutting Item Count (CICT) | 1 |
| Grade | GP50A |
| Tool Type | Threading Regular Inserts |
| Coating | TiCN+TiN |
| Measurement Type | Metric |
| Cutting Edge Material | Carbide |
| Body Material | Carbide |
| Application | | External Thread Milling | External Threading | Treading Inserts | |
| Thread Form Type (THFT) | M60 |
| Applicable Material | | Steel | Stainless Steel | |
