MTEC 1212C34 10UN AC22
Item #: FG335603883
Brand: Tool-Flo
Model #: 1271074
| Product Specifications | |
|---|---|
| Thread Pitch (TP) | 2.54 mm |
| Flute Helix Angle (FHA) | 15 Degrees |
| Threads per Inch (TPI) | 10 Threads/" |
| Cutting Edge Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 0.472″ |
| Cutting Position | INT |
| Cutting Diameter (DC) | 0.472″ |
| Measurement Type | Inch |
| Overall Length (OAL) | 3.268″ |
| Grade | AC22 |
| Flute Count (NOF) | 3 |
| Depth of Cut Maximum (APMX) | 1.3504″ |
| Shank Type | Round |
| Body Material | Carbide |
| Coating | TiAlN |
| Connection Code Machine Side (CCMS) | R47.24400 |
| Application | | Internal Thread Milling | |
| Thread Form Type (THFT) | UN60 |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Hi Temp Alloys | |
