MTEC 0750D17 7UN AC22
Item #: FG335604468
Brand: Tool-Flo
Model #: 1271054
| Product Specifications | |
|---|---|
| Threads per Inch (TPI) | 7 Threads/" |
| Flute Helix Angle (FHA) | 15 Degrees |
| Connection Diameter Machine Side (DCONMS) | 3/4″ |
| Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 3/4″ |
| Cutting Position | INT |
| Overall Length (OAL) | 4″ |
| Measurement Type | Inch |
| Flute Count (NOF) | 4 |
| Grade | AC22 |
| Shank Type | Round |
| Depth of Cut Maximum (APMX) | 1.78″ |
| Coating | TiAlN |
| Body Material | Carbide |
| Application | | Internal Thread Milling | |
| Connection Code Machine Side (CCMS) | ZYL01R7500h$06 |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Hi Temp Alloys | |
| Thread Form Type (THFT) | UN60 |
