E10Q SCLPL2 Solid Carbide Boring Bar w/Coolant
Item #: FG551169
Brand: Ultra-Dex
Model #: 920-000-254
| Product Specifications | |
|---|---|
| Connection Diameter Machine Side (DCONMS) | 5/8″ |
| Coolant Supply Property (CSP) | Coolant Thru |
| Minimum Bore Diameter (DMIN) | 0.77″ |
| Functional Width (WF) | .406″ |
| Functional Length (LF) | 7″ |
| Master Insert Identification (MIID) | CPMT 21.51 |
| Cutting Direction (HAND) | Left Hand |
| Overall Length (OAL) | 7″ |
