Brand: Seco / Part #: 10138996

Brand: Seco / Part #: 10138996


Item #: 98676919
Brand: Seco
Model #: 10138996

Product Specifications

Thread Size (mm) M6
Chamfer Bottoming
Class Of Fit 6HX
Number Of Flutes 3
Material HSS-E-PM
Threads per Inch 25
Thread Direction Right Hand
Flute Direction Right Hand
Coating/Finish HL
Thread Depth (mm) 10.00
Coolant Through No
Thread Length (mm) 10.00
Overall Length (mm) 82.4000
Thread Pitch (Decimal Inch) 0.0394
Thread Pitch (mm) 1.00
Thread Standard Metric
Helix Angle 45.00
Oversize No
Application Blind Hole Threading
Shank Diameter (mm) 6.0000
Neck Length (mm) 20.00
Tapping Depth (mm) 30.00
Flute Style Spiral
Material Application Non-Ferrous Metal; Superalloy; Stainless Steel; Cast Iron; Steel
Series T34
Shank Length (mm) 52.400
$ 57.72
