2NCVBGA222-BNC500 Turning Insert
Item #: FJ0316JZDJC
Brand: Sumitomo
Model #: 16JZDJC
| Product Specifications | |
|---|---|
| Applicable Material | Cast Iron|Exotic Alloys|Hardened Steel |
| Grade | BNC500 |
| Insert Style | VBGA |
| Tool Type | Turning Insert |
| Corner Radius (RE) | 0.031″ |
| Fixing Hole Diameter (D1) | 0.134″ |
| Insert Size | 222 |
| Depth of Cut Maximum (APMX) | 0.015″ |
| Insert Thickness (S) | 1/8″ |
| Clearance Angle Major (AN) | 5 Degrees |
| Inscribed Circle Diameter (IC) | 1/4″ |
| Number of Cutting Edges | 2 |
| Cutting Edge Material | PCBN |
| Shape | 35° Diamond |
