TXGSM22I025-13-00
Item #: IC522742927
Brand: Ingersoll
Model #: 2742927
| Product Specifications | |
|---|---|
| Cutting Diameter (DC/DCX) | 2-1/2″ |
| Overall Length (OAL) | 2.17″ |
| Cutting Diameter (DC) | 2.44″ |
| Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 2-1/2″ |
| Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 13 |
| Application | | BALANCIN | Facing | Slanted Shoulder & Chamfer | |
| Depth of Cut Maximum (APMX) | 0.16″ |
| Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 0.866″ |
| Tool Cutting Edge Angle (KAPR) | 75 Degrees |
