1EJ5C-1001780R01
Item #: IC522925694
Brand: Ingersoll
Model #: 2925694
| Product Specifications | |
|---|---|
| Cutting Diameter (DC/DCX) | 1″ |
| Connection Diameter Machine Side (DCONMS) | 1″ |
| Cutting Diameter (DC) | 1″ |
| Usable Length (LU) | 1.55″ |
| Cutting Item Count (CICT) | 2 |
| Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Depth of Cut Maximum (APMX) | 0.385″ |
| Measurement Type | Inch |
| Overall Length (OAL) | 4″ |
| Body Material | Steel |
| Ramping Angle Maximum (RMPX) | 1.99 Degrees |
| Protruding Length (LPR) | 1-3/4″ |
| Application | | Facing | Helical Interpolation | Rampdown | Shouldering | Slotting | |
