GTADP29360734N6R01
Item #: IC524855696
Brand: Ingersoll
Model #: 4855696
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1.156″ |
| Flange Diameter (DF) | 1.772″ |
| Usable Length (LU) | 28.9″ |
| Point Length (PL) | 0.102″ |
| Application | | Drill Mill | Drilling | |
| Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ |
| Length Group | 25× |
| Shank Length (LS) | 2.362″ |
| Body Material | Steel |
| Functional Length (LF) | 31.55″ |
| Decimal Equivalent | 1.156″ |
| Overall Length (OAL) | 34.27″ |
