Brand: Ingersoll Cutting Tools / Part #: 6321693
Item #: 67311118
Brand: Ingersoll Cutting Tools
Model #: 6321693
Product Specifications
| Insert Style | HNGU |
| Insert Size Code | 0605 |
| Insert Material | Carbide |
| Manufacturer Grade | IN6537 |
| Inscribed Circle (mm) | 14.00 |
| Insert Hand | Right Hand |
| Series | HNGU |
| Coating Process | MTCVD |
| Maximum Depth of Cut (Decimal Inch) | 0.2300 |
| Number Of Cutting Edges | 12 |
| Insert Shape | Hexagon |
| Rake | Negative |
| Primary Workpiece Material | Stainless Steel; Cast Iron; Steel |
| Primary Workpiece Material Code | P; K; M |
| Ansi Code | HNGU0605ANTR-M |
| Rake Angle | 0.000 |
| Manufacturers Catalog Number | HNGU0605ANTR-M IN6537 |
| Cutter Series Compatibility | HN5D |
| Chip Breaker | M |
| Cutting Direction | Right Hand |
| Shape | Hexagon |
| Insert Holding Method | Screw |
| Coating Classification | CVD |
| Single or Double Sided Insert | Double |
| Coating/Finish | TiCN; TiN; Al2O3 |
| Included Angle Degree | 120 |
| Length | 14.00 |
| Width (Mm - 2 Decimals) | 14.00 |
| Thickness (Decimal Inch - 4 Decimals) | 0.2640 |
| Multi-Use Tool | No |
