Brand: Ingersoll Cutting Tools / Part #: 6335110
Item #: 01027135
Brand: Ingersoll Cutting Tools
Model #: 6335110
Product Specifications
| Maximum Drill Diameter (mm) | 16.90 |
| Point Angle | 0.00 |
| Diameter (mm) | 16.9000 |
| Tip Material | Solid Carbide |
| Manufacturer Grade | IN2205 |
| Cutting Direction | Right Hand |
| Series | FPC |
| Coating Process | PVD |
| Insert Seat Size | 16 |
| Primary Workpiece Material | Cast Iron; Steel |
| Primary Workpiece Material Code | P; K |
| Height (mm) | 8.9900 |
| Head Length (mm) | 8.99 |
| Cutting Diameter (mm) | 16.90 |
| Flute Type | Helical |
| Insert Holding Method | Twist |
| ISO Number | FPC1690R01 IN2205 |
| Coolant Through | Yes |
| Flute Length (mm) | 5.28 |
| Point Type | Self Centering |
| Overall Length/Projection (mm) | 8.99 |
| Spiral Type | Regular |
| Style | FPC |
| Coating Classification | PVD |
| Applications | Drilling |
| Coating/Finish | TiAlSiN; AlTiN |
| Number Of Flutes | 3 |
