1/4″ Dia. × 1/4″ Shank × 1/2″ DOC × 4″ OAL, Exxtral Carbon (DLC), 3 Flute, 37° Helix, Straight, External, Square, Solid End Mill

1/4″ Dia. × 1/4″ Shank × 1/2″ DOC × 4″ OAL, Exxtral Carbon (DLC), 3 Flute, 37° Helix, Straight, External, Square, Solid End Mill


Item #: CW8058068
Brand: Precision Cutting Tools
Model #: 9523037

Product Specifications
Cutting Diameter (DC) 1/4″
Neck Diameter (DN) 0.235″
Connection Diameter Machine Side (DCONMS) 1/4″
Peripheral Effective Cutting Edge Count (ZEFP) 3
Depth of Cut Maximum (APMX) 1/2″
Tool Type Solid Carbide Endmill
Overall Length (OAL) 4″
Maximum Feed per Tooth (fz(max)) 0.002″
Coating Exxtral Carbon (DLC)
Minimum Feed per Tooth (fz(min)) 0.001″
Flute Count (NOF) 3
Length Group Standard - Necked
Flute Helix Angle (FHA) 37 Degrees
Coolant Supply Property (CSP) External
Shank Type Straight
Shank Standard h6
End Shape Square
Body Material Carbide
Usable Length (LU) ‎2-1/8″
Style Necked
Applicable Material Non Ferrous
Decimal Equivalent 0.25″
Application Slotting | Roughing | HEM | Semi-Finish | Finish
Measurement Type Inch
Corner Radius (RE) 0″
Series/List # 337
Grade A5005
Shank Size (SS) 1/4″
Country of Origin USA
$ 78.99
