Brand: Widia / Part #: 3655927

Brand: Widia / Part #: 3655927


Item #: 98384258
Brand: Widia
Model #: 3655927

Product Specifications

Internal or External External
Maximum Depth of Cut (Decimal Inch) 0.5600
Hand of Holder Left Hand
Maximum Groove Width (Decimal Inch) 0.2500
Minimum Groove Width (Decimal Inch) 0.3150
Toolholder Style WMTSL
Tool Material Steel
Insert Holding Method Clamp
Compatible Insert Size Code S250
Insert Compatibility WMTS250I6P03PT
Shank Height (Inch) 1
Shank Height (Decimal Inch) 1.0000
Shank Length (Decimal Inch) 4.5620
Shank Width/Diameter (Decimal Inch) 1.0000
Shank Width/Diameter (Inch) 1
Series WMT
Overall Length (Decimal Inch) 6.0000
Cutting Tool Application Grooving; Cut-Off; Turning
Back of Bar to Cutting Edge (Decimal Inch) 1.0040
Head Height (mm) 34.930
Head Length (Decimal Inch) 1.4382
Primary Workpiece Material Universal
Insert Seat Size 6.0
Coolant Through No
$ 156.08
