16 IR150ISOTQ PR1535 Grade PVD Carbide, Indexable Threading Insert
Item #: KY90TLC19730
Brand: Kyocera Precision Tools
Model #: TLC19730
| Product Specifications | |
|---|---|
| Thread Standard | Metric |
| Applicable Material | Stainless Steel |
| Inscribed Circle Diameter (IC) | 9.525 mm |
| Insert Style | 16IR |
| Thread Pitch (TP) | 1.5 mm |
| Mounting Style | Clamp | Screw |
| Corner Radius (RE) | 0.11 mm |
| Cutting Direction (HAND) | Right Hand |
| Insert Thickness (S) | 3.68 mm |
| Chip Breaker Type | TQ |
| Grade | PR1535 |
| Cutting Item Count (CICT) | 3 |
| Coating | MEGACOAT NANO |
| Series/List # | LDT |
| Cutting Edge Material | Carbide |
| Measurement Type | Metric |
| Cutting Position | Internal |
| Hole Diameter | 4 mm |
| Application | Internal Threading |
| Profile Included Angle (PNA) | 60 Degrees |
