1000275AL 1.0000 EM
Item #: KY968601007
Brand: Kyocera Precision Tools
Model #: OTM86401
| Product Specifications | |
|---|---|
| Cutting Diameter (DC/DCX) | 1″ |
| Functional Length (LF) | 2-3/4″ |
| Cutting Diameter (DC) | 1″ |
| Tool Type | End Mill |
| Cutting Item Count (CICT) | 2 |
| Usable Length (LU) | 0.64″ |
| Overall Length (OAL) | 4.78″ |
| Flute Count (NOF) | 2 |
| Shank Type | Weldone |
| Coolant Supply Property (CSP) | Coolant Thru |
| Ramping Angle Maximum (RMPX) | 8 Degrees |
| Style | EM |
| Application | Facing | Shouldering | Slotting of Aluminum |
| Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 3/4″ |
| Angle | 90 Degrees |
| Master Insert Identification (MIID) | APET1604PDFR | APET160416 | APET160431 |
| Series/List # | EM-AL |
| Head Length (LH) | 3.78″ |
| Measurement Type | Inch |
