Brand: Widia / Part #: 3883458

Brand: Widia / Part #: 3883458


Item #: 02774396
Brand: Widia
Model #: 3883458

Product Specifications

Minimum Bore Diameter (mm) 32.000
Maximum Bore Depth (mm) 75.00
Toolholder Style PWLNR
Tool Material Steel
Shank Diameter (mm) 25.0000
Hand of Holder Right Hand
Overall Length (mm) 200.0000
Compatible Insert Size Code WN..080408
Insert Holding Method Lever
Compatible Insert Shape Trigon
Insert Included No
Rake Negative
Cutting Direction Right Hand
Rake Angle -12.000
Lead Angle 95.000
Series A-PWLN
Insert Inscribed Circle (Inch) 1/2
Compatible Insert Thickness (Decimal Inch) 0.1875
Compatible Insert Thickness (mm) 4.76
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (mm) 29.50
Center to Cutting Edge (mm) 17.00
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.1875
Insert Thickness (Inch) 3/16
Coolant Hole Diameter (mm) 6.40
Number of Inserts Included in Order 0
Manufacturers Catalog Number A25RPWLNR08
Radial Rake -5
Coolant Through Yes
$ 268.79
