Electro Hardware - #2 Screw 5/8" OAL 0.089" ID x 1/4" OD Round Stainless Steel Circuit Board Spacers - Exact Tooling

Electro Hardware - #2 Screw 5/8" OAL 0.089" ID x 1/4" OD Round Stainless Steel Circuit Board Spacers


Item #: 67712729
Brand: Electro Hardware
Model #: S537-M07-F16-C

Features and Benefits

Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
Product Specifications
Type Female Unthreaded
Material Stainless Steel
System of Measurement Inch
Body Shape Round
Screw Size #2
Outside Diameter (Decimal Inch) 0.2500
Outside Diameter (Inch) 1/4
Overall Length (Decimal Inch) 0.6250
Overall Length (Inch) 5/8
Inside Diameter (Decimal Inch) 0.089
Finish/Coating Uncoated
Material Grade 18-8; Grade 303
Inside Diameter Tolerance (Decimal Inch) 0.000 to 0.010
Length Tolerance (Decimal Inch) -0.005 to 0.005
Fastener Standard QQ-S-763
$ 3.43
