601 STRAIGHT LINE ACTION
Item #: MA50601
Brand: De-Sta-Co
Model #: 601
| Product Specifications | |
|---|---|
| Style | Straight Line |
| Mounting Length | .63″ |
| Type | Toggle Clamp |
| Mounting Width | .63″ |
| Arm | 1.05″ |
| Overall Width | 1.05″ |
| Holding Capacity | 100 lbs |
| Plunger Height | .50″ |
| Overall Height | 1.27″ |
| Plunger Travel | .63″ |
| Overall Length | 2.61″ |
| Spindle Size | #8-32 |
| Thread Size | #8-32 |
| Base Length | 1.33″ |
| Model No | 601 |
| Plunger Diameter | .25″ |
| Bar Style | Plunger |
| Toggle Lock Plus Lever | No |
| Distance From Surface to Plunger | 0.50″ |
| Bar Type | Flanged |
| Mounting Diameter | 0.17″ |
