SEEN42AFTN1 NX2525 INSERT
Item #: MB02115883
Brand: Mitsubishi Materials USA
Model #: 115883
| Product Specifications | |
|---|---|
| Applicable Material | Steel | Stainless Steel | Cast Iron |
| Insert Style | SEEN |
| Corner Radius (RE) | 1 mm |
| Clearance Angle Major (AN) | 20 Degrees |
| Inscribed Circle Diameter (IC) | 12.7 mm |
| Series/List # | NX2525 |
| Insert Thickness (S) | 3.18 mm |
| Cutting Edge Material | Cermet |
| Wiper Edge Length (BS) | 1.4 mm |
| Tool Type | rotating_inserts |
| Grade | NX2525 |
| Measurement Type | Metric |
