SPMW422 NX2525
Item #: MB02200491
Brand: Mitsubishi Materials USA
Model #: 200491
| Product Specifications | |
|---|---|
| Applicable Material | Steel | Stainless Steel | Cast Iron |
| Clearance Angle Major (AN) | 11 Degrees |
| Corner Radius (RE) | 0.8 mm |
| Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 12.7 mm |
| Chip Breaker Type | flat_top |
| Insert Thickness (S) | 3.18 mm |
| Series/List # | NX2525 |
| Insert Included Angle (EPSR) | 90 Degrees |
| Hole Diameter | 5.7 mm |
| Grade | NX2525 |
| Cutting Edge Material | Cermet |
| Shape | Square |
| Measurement Type | Metric |
