TECN32PEER1W HTI10
Item #: MB02339477
Brand: Mitsubishi Materials USA
Model #: 339477
| Product Specifications | |
|---|---|
| Applicable Material | Cast Iron | Aluminum / Non-Ferrous Materials |
| Clearance Angle Major (AN) | 20 Degrees |
| Corner Radius (RE) | 0.4 mm |
| Series/List # | HTi10 |
| Inscribed Circle Diameter (IC) | 9.525 mm |
| Cutting Edge Material | Carbide |
| Insert Thickness (S) | 3.175 mm |
| Measurement Type | Metric |
| Grade | HTi10 |
