TECN32PETR1W NX2525
Item #: MB02399744
Brand: Mitsubishi Materials USA
Model #: 399744
| Product Specifications | |
|---|---|
| Applicable Material | Steel | Stainless Steel | Cast Iron |
| Clearance Angle Major (AN) | 20 Degrees |
| Corner Radius (RE) | 0.4 mm |
| Series/List # | NX2525 |
| Inscribed Circle Diameter (IC) | 9.525 mm |
| Cutting Edge Material | Cermet |
| Insert Thickness (S) | 3.175 mm |
| Measurement Type | Metric |
| Grade | NX2525 |
