VC2CD1200
Item #: MB03303634
Brand: Mitsubishi Materials USA
Model #: 303634
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 12 mm |
| End Shape | Chamfer |
| Connection Diameter Machine Side (DCONMS) | 12 mm |
| Peripheral Effective Cutting Edge Count (ZEFP) | 2 |
| Depth of Cut Maximum (APMX) | 5.75 mm |
| Length Group | Medium |
| Overall Length (OAL) | 75 mm |
| Measurement Type | Metric |
| Coating | VC |
| Series/List # | VC2C |
| Flute Helix Angle (FHA) | 5 Degrees |
| Tool Cutting Edge Angle (KAPR) | 45 Degrees |
