VQSVRD1800
Item #: MB03803410
Brand: Mitsubishi Materials USA
Model #: 803410
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 18 mm |
| Corner Radius (RE) | 0.5 mm |
| Connection Diameter Machine Side (DCONMS) | 16 mm |
| Peripheral Effective Cutting Edge Count (ZEFP) | 4 |
| Depth of Cut Maximum (APMX) | 33 mm |
| Length Group | Short |
| Overall Length (OAL) | 150 mm |
| Measurement Type | Metric |
| Coating | VQ |
| Series/List # | VQSVR |
| End Shape | Corner Radius |
