Kyocera - Indexable High-Feed End Mills Maximum Depth of Cut (mm): 31.75 Maximum Depth of Cut (Decimal Inch): 1.2500
Item #: 16391161
Brand: Kyocera
Model #: 8609377
Product Specifications
Indexable High-Feed End Mills; Maximum Depth of Cut (mm): 31.75 ; Maximum Depth of Cut (Decimal Inch): 1.2500 ; Shank Type: Cylindrical ; Shank Diameter (mm): 31.7500 ; Shank Diameter (Decimal Inch): 1.2500 ; Number of Cutter Inserts: 5
| Maximum Depth of Cut (mm) | 31.75 |
| Maximum Depth of Cut (Decimal Inch) | 1.2500 |
| Shank Type | Cylindrical |
| Shank Diameter (mm) | 31.7500 |
| Shank Diameter (Decimal Inch) | 1.2500 |
| Number of Cutter Inserts | 5 |
| Insert Style | LOGU03 |
| Toolholder Style | MFH |
| Insert Holding Method | Screw |
| Weldon Flat | No |
| End Mill Type | High Feed |
| Number of Flutes | 5 |
| Maximum RPM | 11400.000 |
| Through Coolant | Yes |
| Head Length (Decimal Inch) | 3.0000 |
| Maximum Cutting Diameter (Decimal Inch) | 1.2500 |
| Overall Length (mm) | 158.7500 |
| Overall Length (Decimal Inch) | 6.25000 |
| Toolholder Material | Steel |
| Series | MFH-Mini |
| Lead Angle | 10 |
| Head Length (mm) | 76.20 |
| Manufacturers Catalog Number | MFH1250S125035T62 |
