Brand: Widia / Part #: 5357285
Item #: 70743455
Brand: Widia
Model #: 5357285
Product Specifications
| Thread Size (Inch) | #6-32 |
| Number Of Flutes | 2 |
| Chamfer | Plug |
| Thread Limit | H3 |
| Class Of Fit | 2B/3B |
| Coating/Finish | Oxide |
| Threads per Inch | 32 |
| Material | Vanadium High Speed Steel |
| Coolant Through | Yes |
| Thread Direction | Right Hand |
| Thread Depth (Decimal Inch) | 0.3800 |
| Thread Pitch (Decimal Inch) | 0.0313 |
| Thread Standard | UNC; UNF |
| Thread Length (Decimal Inch) | 0.3800 |
| Overall Length (Decimal Inch) | 1.9900 |
| Cnc Shank | Yes |
| Oversize | No |
| Shank Diameter (Decimal Inch) | 0.1410 |
| Application | Through-Hole Threading |
| Neck Length (Decimal Inch) | 0.2740 |
| Tapping Depth (Decimal Inch) | 0.7500 |
| Square Length (Decimal Inch) | 0.1900 |
| Square Size (Decimal Inch) | 0.1080 |
| Material Application | Stainless Steel; Cast Iron; Steel |
| Series | VTSPO |
| Style | Plug |
