Brand: Widia / Part #: 2829764

Brand: Widia / Part #: 2829764


Item #: 70731633
Brand: Widia
Model #: 2829764

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.3580
Maximum Bore Depth (Decimal Inch) 3.1250
Toolholder Style FCBI
Tool Material Solid Carbide
Insert Compatibility TD..
Shank Diameter (Decimal Inch) 0.3120
Hand of Holder Right Hand
Overall Length (Decimal Inch) 6.0000
Compatible Insert Size Code 130805
Insert Holding Method Screw
Compatible Insert Shape Triangle
Insert Included No
Rake Neutral (Radial); Positive (Axial)
Cutting Direction Right Hand
Rake Angle 5.000
Lead Angle 95.000
Series FCBI
Insert Inscribed Circle (Decimal Inch) 0.1600
Compatible Insert Thickness (Decimal Inch) 0.0470
Multi-use Tool Yes
Cutting Tool Application Turning; Boring
Back of Bar to Cutting Edge (Decimal Inch) 6.0000
Center to Cutting Edge (Decimal Inch) 0.1870
Primary Workpiece Material Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel
Primary Workpiece Material Code P; K; M; N
Multi-Use Application External Turning; Internal Turning; Turning; Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0470
Coolant Hole Diameter (Decimal Inch) 0.0930
Coolant Hole Diameter (mm) 2.36
Insert Size 130805
Body Diameter 0.3120
Model Number FCBI-312-6-5R
Insert Style TD..
Coolant Through Yes
$ 271.76
