Brand: Widia / Part #: 2836667

Brand: Widia / Part #: 2836667


Item #: 28913986
Brand: Widia
Model #: 2836667

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.1800
Maximum Bore Depth (Decimal Inch) 0.5000
Maximum Bore Depth (Inch) 1/2
Toolholder Style ABC
Tool Material Carbide
Shank Diameter (Decimal Inch) 0.1560
Hand of Holder Right Hand
Shank Diameter (Inch) 5/32
Overall Length (Decimal Inch) 1.0500
Compatible Insert Size Code CD..120605
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle 0.000
Lead Angle -7.000
Series ABC
Insert Inscribed Circle (Inch) 5/32
Insert Inscribed Circle (Decimal Inch) 0.1563
Insert Inscribed Circle (mm) 3.97
Compatible Insert Thickness (Decimal Inch) 0.0400
Compatible Insert Thickness (mm) 1.02
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.1730
Center to Cutting Edge (Decimal Inch) 0.0950
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Neck Diameter (Decimal Inch) 0.1640
Insert Thickness (Decimal Inch) 0.0400
Coolant Hole Diameter (Decimal Inch) 0.0400
Number of Inserts Included in Order 0
Manufacturers Catalog Number ABC500R
Radial Rake 0
Coolant Through Yes
$ 277.55
