Straight Flute Tap; 1/4″ -20 × 2-1/2″ OAL, 4 Flute, HSS, Uncoated, H3
Item #: TA15TT90323
Brand: Titan USA
Model #: TT90323
| Product Specifications | |
|---|---|
| Thread Diameter Size (TDZ) | 1/4″ |
| Cutting Edge Material | HSS |
| Threads per Inch (TPI) | 20 |
| Thread Tolerance Class (TCTR) | | H3 | |
| Thread Standard | | UN | |
| Special Feature | General Purpose |
| Overall Length (OAL) | 2-1/2″ |
| Standard | | ANSI | |
| Thread Cutting Part Length (THL) | 1″ |
| Chamfer | Taper |
| Usable Length (LU) | 1″ |
| Coating | Uncoated |
| Connection Diameter Machine Side (DCONMS) | 0.255″ |
| Measurement Type | Inch |
| Flute Count (NOF) | 4 |
| Thread Size | 1/4″ - 20 |
| Flute Helix Angle (FHA) | 0 Degrees |
