EXLS02M008C08.0LH30R01
Item #: TG256770129
Brand: Tungaloy
Model #: 6770129
| Product Specifications | |
|---|---|
| Cutting Diameter (DC/DCX) | 4.29 mm |
| Master Insert Identification (MIID) | LSMT0202ZER-HM |
| Cutting Diameter (DC) | 4.29 mm |
| Weight of Item (WT) | 0.03 kg |
| Cutting Diameter Maximum (DCX) | 8 mm |
| Head Length (LH) | 31 mm |
| Cutting Item Count (CICT) | 1 |
| Functional Length (LF) | 90 mm |
| Depth of Cut Maximum (APMX) | 0.5 mm |
| Tool Type | CUTTER - SHANK TYPE |
| Overall Length (OAL) | 90 mm |
| Tool Cutting Edge Angle (KAPR) | 12 Degrees |
| Shank Type | Round |
| Measurement Type | Metric |
| Application | | Face Milling | High Feed Milling | |
| Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 8 mm |
