5/16-24 UNF 2B IF1-GA-L-SN-IKZ
Item #: ER4511216
Brand: EMUGE-FRANKEN
Model #: BU38Q200.5044
| Product Specifications | |
|---|---|
| Tool Type | Modified Bottoming Form Tap |
| Coating | TiCN |
| Thread Diameter Size (TDZ) | 5/16″ |
| Coolant Supply Property (CSP) | Coolant Thru |
| Overall Length (OAL) | 3.543″ |
| Threads per Inch (TPI) | 24 |
| Usable Length (LU) | 32 mm |
| Chamfer | 2P-3P |
| Connection Diameter Machine Side (DCONMS) | 0.318″ |
| Cutting Edge Material | HSSE-PM |
| Thread Tolerance Class (TCTR) | | 2BX | |
| Cutting Direction (HAND) | Right Hand |
| Thread Standard | | UNF | |
| Series/List # | U38Q200 |
| Application | Through Hole | Blind Hole |
| Thread Size | 5/16″ - 24 |
| Applicable Material | | Aluminum / Non-Ferrous Materials | |
