1/16-27 NPS 3FX A-NPS V
Item #: TP131659001008
Brand: OSG USA, Inc.
Model #: 1659001008
| Product Specifications | |
|---|---|
| Thread Diameter Size (TDZ) | 1/16″ |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials |
| Threads per Inch (TPI) | 27 |
| Chamfer | 2.5P |
| Thread Standard | NPS |
| Coating | V Coating |
| Flute Count (NOF) | 3 |
| Cutting Edge Material | HSSE |
| Overall Length (OAL) | 3.543″ |
| Measurement Type | Inch |
| Thread Cutting Part Length (THL) | 0.551″ |
| Square Size | 0.234″ |
| Connection Diameter Machine Side (DCONMS) | 0.313″ |
| Series/List # | 16590 |
| Flute Type | Spiral |
| Thread Size | 1/16″ - 27 |
| Cutting Direction (HAND) | Right Hand |
